Core Technical Parameters:
- Voltage Rating: 3 kV – 13.8 kV
- Power Range: 185 kW – 1,600 kW
- Pole Configuration: 2–12 poles
- Protection Class: IP55, IP56
- Insulation / Temperature Rise Class: F/B, H/B (optional)
- Operating Frequency: 50 Hz
- Duty Type: Continuous duty (S1)
- Operating Environment: Altitude ≤ 1,000 m; Ambient temperature –15 °C to +40 °C (extended: –20 °C to +40 °C)
- Explosion-Proof Type: Ex d I, Ex d IIB T4, Ex d IIC T4
- Frame Range: H355–560
- Mounting Type: IMB3 standard horizontal mounting
- Applicable Standards: GB3836 series national explosion-proof standards, IEC60079-1, EN50018 international explosion-proof specifications
Product Features:
Compact structure, light weight, high efficiency and energy savings, low noise and vibration, high reliability, long service life, and convenient installation and maintenance, suitable for demanding high-voltage explosion-proof operating conditions.
Application Scenarios:
High-voltage power equipment in petroleum, chemical, coal, power station, metallurgical, textile, pharmaceutical, grain processing, and other explosive gas industries.
