Core Technical Parameters:
- Voltage Rating: 3000V – 15750V
- Power Range: 2,000 kW – 150,000 kW (2,700 – 201,000 Hp)
- Speed Range: 1500 – 3600 rpm
- Protection Class: IP21 to IP56 (optional, suitable for indoor and outdoor conditions)
- Cooling Method: IC81W, IC86W, IC611, IC616, IC666, IC01
- Installation Method: IMB3
- Explosion-proof Type: Ex ec, Ex pxb, Ex pzc
- Rotor Material: Alloy forged steel
- Bearing Options: End-cover sliding bearing
- Standards: GB, IEC, EN
- Certification: IECEx, CCC, CE
- Prime Mover: Steam turbine, industrial turbine, gas turbine, diesel engine
Note: The above are default parameters. For other special requirements, please contact our company.
Operating Conditions:
- Ambient Air Temperature: -20°C to +40°C (standard) / -60°C to +60°C (custom)
- Monthly Average Maximum Relative Humidity: ≤90% (at 25°C)
- Altitude: ≤1000m (standard) / 1000m – 5000m (custom)
Product Features:
- High Reliability: Redundant excitation system design; nuclear-grade insulation system; rotor balance grade up to G1.0.
- Excellent Performance: High efficiency, low vibration; high protection class with compact size and light weight; strong environmental adaptability.
- Easy Installation: Box-type structure saves installation space; complete-unit shipment for convenient on-site installation; maintenance-free.
- Wide Application: Mobile power stations, captive power stations, waste heat and waste pressure power generation, biomass power generation, solar thermal power generation, offshore platforms, and more.
Application Scenarios: Small power plants, mobile power stations, captive power stations, waste heat and waste pressure power generation, biomass power generation, solar thermal power generation, offshore platforms, and other power generation facilities. Special variants including explosion-proof, ultra-lightweight, air-to-air cooled, low-temperature, and double-shaft-extension generators are available upon request.
