Core Technical Parameters:
- Voltage Rating: 6000V – 15750V (high-voltage)
- Power Range: 30,000 kW – 150,000 kW (40,200 – 201,000 Hp)
- Speed Range: 1500 – 3600 rpm
- Protection Class: IP21 to IP56 (optional, suitable for indoor and outdoor conditions)
- Cooling Method: IC81W
- Installation Method: IMB3
- Rotor Material: Alloy forged steel
- Bearing Options: End-cover bearing, Pedestal bearing
- Standards: GB, IEC
- Customizable: Operating Frequency 50 Hz / 60 Hz; Insulation Class F / H; Power Factor 0.8 / 0.9; Duty Type S1 continuous
Note: The above are default parameters. For other special requirements, please contact our company.
Operating Conditions:
- Ambient Air Temperature: -20°C to +40°C (standard) / -60°C to +60°C (custom)
- Monthly Average Maximum Relative Humidity: ≤90% (at 25°C)
- Altitude: ≤1000m (standard) / 1000m – 5000m (custom)
Product Features:
- High Reliability: Bearing positive pressure air sealing; advanced VP1 insulation system; suitable for frequent starting conditions.
- Excellent Performance: Low vibration, low noise, high efficiency; dual-condition full-load output for both motor and generator operation.
- Easy Maintenance: Single mechanical brush for convenient live replacement; large wiring cavity for easy wiring; dedicated inspection doors and windows.
- Wide Application: Air energy storage, energy recovery, and other industrial sectors.
Application Scenarios: Air energy storage plants, energy recovery systems, and other industrial applications requiring both motor and generator capabilities.
