Core Parameters:
- Voltage Rating: 6 kV, 3 kV, 380V
- Power Range: 160 kW – 2,000 kW
- Pole Configuration: 6P, 8P, 10P
- Protection Class: IP54, IP55
- Insulation / Temperature Rise Class: Class F / Class B
- Operating Frequency: 50 Hz
- Cooling Method: Default: IC611 air-to-air cooling; customizable: IC81W air-to-water cooling
- Mounting Type: IMB3
- Structural Type: Box-type structure
- Operating Environment: Altitude ≤ 1,000 m; Ambient temperature ≤ 40 °C
- Frame Number: 400–800
- Duty Type: Continuous duty (S1)
Product Features:
Excellent dust and water resistance, cooling system adapted for heavy-load operating conditions, capable of long-term continuous stable operation. Mature technology with convenient maintenance.
