Core Technical Parameters:
- Voltage Rating: 6 kV, 10 kV
- Power Range: 200–9,000 kW
- Pole Configuration: 2P, 4P, 6P, 8P, 10P, 12P
- Protection Class: IP23, IP44, IP54, IP55 (optional)
- Insulation / Temperature Rise Class: Class F / Class B
- Operating Frequency: 50 Hz ± 1%
- Cooling Method: IC01, IC611, IC616, IC666, IC81W, IC86W (optional)
- Mounting Type: IMB3
- Structural Type: Box-type structure
- Operating Environment: Altitude ≤ 1,000 m; Ambient temperature ≤ 40 °C
- Frame Number: 355–1000
Product Features:
High efficiency, low noise, low vibration, light weight, and reliable performance, with convenient installation and maintenance, and low overall operating cost.
Application Scenarios:
Compatible with compressors, ventilation fans, water pumps, crushers, and other general-purpose mechanical equipment. Widely used in mining, machinery, petrochemical, power generation, metallurgical, and other industrial and mining enterprises.
